Description

UNMATCHED SPEED, UNRIVALED QUALITY

Delivering crisp, high-resolution labels with speed and efficiency

The TSC MH361T is a high-resolution industrial thermal transfer label printer designed for precision printing in industries like healthcare, manufacturing, and electronics. With a 300 dpi resolution, it produces sharp, detailed barcodes and small text, ideal for high-density labels. It features a 4.3-inch color touchscreen for easy operation and print speeds up to 14 inches per second for efficient workflow. The rugged metal frame ensures durability, while USB, Serial, Ethernet, and optional Bluetooth/Wi-Fi provide versatile connectivity. The MH361T is perfect for businesses needing high-quality, reliable, and high-speed label printing.



Features:

  • Dual printing methods (Direct Thermal; Thermal Transfer)
  • Big 4.3-inch color LCD touchscreen (480×272) with physical buttons
  • Supports multiple interface options (USB, RS-232, Parallel, Ethernet)
  • Optional wireless connectivity (Wi-Fi (802.11 a/b/g/n/ac) + Bluetooth 4.2)
  • Enhanced remote management tools (TSC Sense Care (“TPH Care”) for printhead health, plus software tools like SOTI Connect and TSC Console)



Applications:

  • 🏭  Manufacturing
  • 🚚  Transportation / Logistics
  • 🏥  Healthcare



Specifications:

Printing Technology Thermal Transfer + Direct Thermal
Resolution 12 dots/mm (300DPI)
Print Speed (Maximum) Up to 254 mm (10”)/second
Print Width (Maximum) 168 mm (6.61”)
Media source:



• Thermal Transfer Paper
• Coated / Glossy Paper Labels
• Synthetic Labels (Polyester, Polypropylene, Polyethylene)
• Tag Stock (Cardboard / Heavy Paper)
• Specialty Media (includes wristbands, textile labels, cryogenic labels, pre-printed stock, and security labels.)


Media Type: Continuous, die-cut, black mark (Bottom side black mark only), fan-fold, notch (outside wound)
Media Width: 50.8 ~ 172.7 mm (2“~ 6.8“)
Media Thickness: 0.06 ~ 0.268 mm (2.36~ 11.02 mil)
Media Roll Capacity: 208.3mm (8.2'') OD
Media Core Diameter:

3.81 mm / 76.2 mm (1.5”/ 3”)
Label Length: 10 ~ 6604mm (0.39'' ~ 260'')
Barcode:
  • 1D bar code

Code 39, Code 93, Code 128UCC, Code 128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked,
GS1 DataBar, Code 11

  • 2D bar code

PDF-417, Maxicode, DataMatrix, QR code, Aztec
Winding Direction: Face Out
Ink Type: •Thermal Transfer (require ink ribbon)
•Direct Thermal (no ink ribbon required)
Ink Catridge: •Thermal Transfer (require ink ribbon)
•Direct Thermal (no ink ribbon required)
Barcode Font:

• 8 alpha-numeric bitmap fonts
• Monotype Imaging® true type font engine with one CG Triumvirate Bold Condensed scalable font
Environment Conditions: • Operation: 5 ~ 40°C, 20 ~ 85% non-condensing
• Storage: -40 ~ 60°C, 10 ~ 90% non-condensing
Safety Regulations: FCC Class A, CE Class A, UL, CUL, TÜV/Safety
Main Interface: • RS-232
• Centronics
• USB 2.0
• Internal Ethernet, 10/100 Mbps
• USB host, for scanner or PC keyboard
• GPIO (factory option)
• Bluetooth (user option)
Optional Interface:



• Guillotine cutter (full cut)
• Heavy duty cutter (full cut)
• Bluetooth module (serial interface)
• KP-200 Plus keyboard display unit
• KU-007 Plus programmable smart keyboard
Printer Language:

TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL)
Size (W x D x H) and Weight:

357 mm (W) x 313 mm (H) x 514 mm (D)
14.05” (W) x 12.32 (H) x 20.24” (D)

17.8 kg (39.24 lbs)
