TE310

Regular price SGD 1,099.00 Sale price SGD 599.00
view

3 People are viewing this right now

Add to Wishlist Add to Compare

Ask a question
Share
Discover our machines

PRECISION PRINTING IN A COMPACT DESIGN

Ideal for shipping, asset tracking, and compliance labeling

The TSC TE310 is a high-resolution thermal transfer label printer designed for precise and efficient printing in industries like retail, healthcare, and logistics. With a 300 dpi resolution, it delivers sharp, high-quality barcodes and text, ideal for small labels and detailed prints. It supports 4-inch-wide labels and offers fast print speeds up to 5 inches per second. Featuring USB, Serial, and Ethernet connectivity, it ensures seamless integration. Its durable, compact design with an easy-to-use clamshell mechanism allows quick label loading. The TE310 is a reliable, cost-effective solution for businesses needing high-precision labeling.



Features:

  • Print mechanism for kiosk applications
  • 400 MHz 32-bit RISC processor with 128 MB Flash memory
  • Internally scalable true type fonts
  • TSPL-EZD firmware emulates TPLE & TPLZ, and TPLD languages out of & the box
  • Free Windows® drivers and label design & software (available via download)
  • ENERGY STAR® qualified



Applications:

  • 🏭  Manufacturing & Warehousing
  • 🚚  Healthcare
  • 💊  Parcel Post
  • 🏠  Small Office / Home Office
  • 🛒  Retail Marking



Specifications:

Printing Technology Thermal Transfer + Direct Thermal
Resolution 12 dots / mm ( 300 DPI )
Print Speed (Maximum) 127 mm  ( 5 '' ) / second
Print Width (Maximum) 105.7 mm ( 4.16 '' )
Media source
  • Paper (gloss, semi-gloss, matte)
  • Synthetic labels (polypropylene, vinyl)
  • Black mark media (reflective black mark used for label alignment)
Media Type Continuous, die-cut, black mark, fan-fold, notched (outside wound)
Media Width 20 ~ 112 mm ( 0.8 '' ~ 4.4 '' )
Media Thickness 0.06 ~ 0.19 mm ( 2.36 ~ 7.48 mil )
Media Roll Capacity Max. 127 mm ( 5 '' ) OD
Media Core Diameter 25.4 ~ 38 mm ( 1 '' ~ 1.5 '' )
Label Length 5 ~ 11430 mm ( 0.2 '' ~ 450 '' )
Barcode
  • 1D bar code

• Code 128UCC
• Code 128 subsets A, B, C
• EAN128
• Interleaved 2 of 5
• Interleaved 2 of 5 with
check digit
• Code 39
• Code 39 with check digit
• Code 93
• EAN13
• EAN8
• UPCA
• UPCE
• EAN
• UPC 2 (5) digits add-on
• Codabar
• Postnet
• MSI
• MSI with check digit
• PLESSEY
• China post
• ITF14
• Code 11
• TELEPEN
• TELEPENN
• PLANET
• Code49
• Deutsche Post Identcode
• Deutsche Post Leitcode
• LOGMARS

  • 2D bar code

• GS1 DataBar
• GS1 DataMatrix
• Maxicode
• AZTEC
• PDF417
• QR Code
• Micro PDF 417
Winding Direction Face Out
Ink Type • Thermal Transfer (require ink ribbon)
• Direct Thermal (no ink ribbon required)
Ink Catridge • Thermal Transfer (require ink ribbon)
• Direct Thermal (no ink ribbon required)
Barcode Font

• 8 alpha-numeric bitmap fonts
• Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font
Environment Conditions Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
Storage: -40 ~ 60°C, 10 ~ 90% non-condensing
Safety Regulation FCC Class B
• CE Class B
• C-Tick Class B
• UL
• cUL
• TÜV/safety
• CCC
• EAC
• CoC
• BIS
• KC
• Energy Star®
Main Interface • USB 2.0
• Internal Ethernet, 10/100 Mbps
• RS232
• USB host, for scanner or PC keyboard
• Internal Bluetooth 4.0 (factory option)
• External Bluetooth (user option)
Optional Interface • External roll mount, media OD. 214 mm
(8.4”) with 76.2 mm (3”) core
• External Bluetooth module (serial interface)
• KP-200 Plus keyboard display unit
• KU-007 Plus programmable smart keyboard
Printer Language
  • TSPL-EZD ( Compatible to EPL, ZPL, ZPL II, DPL )
Size (W x D x H) and Weight

204 mm ( W ) x 280 mm ( D ) x 164 mm ( H )
8.03“ ( W ) x 11.02“ ( D ) x 6.46“ ( H )

2.5 kg ( 5.51 lbs )
