Zebra 220Xi4

Sale price SGD 8,799.00
view

2 People are viewing this right now

dpi: 203
Add to Wishlist Add to Compare
Discover our machines

Built to Perform. Day In and Day Out. Year After Year.

Legendary rugged durability, print quality and longevity

Zebra’s built-to-last 220Xi4 printer is renowned for it’s incredible durability, consistently outstanding print quality, fast print speed, long life and unparalleled reliability in demanding applications. The 220Xi4 is designed for printing of labels up to 8" wide for chemical drum or other wide label applications. The ZT610 or ZT620 Industrial printers are the preferred printers for high volume print applications with a print width of less than 6.6" (168 mm).



Features:

  • Wide-format printing up to 8.5" (216 mm)
  • 203 dpi standard, 300 dpi optional
  • Fast print speeds up to 10 ips
  • Rugged all-metal construction for 24/7 use
  • Large backlit LCD for easy setup
  • Smart printhead system with diagnostics
  • Standard USB, Serial, Parallel, Ethernet connectivity
  • Supports large label rolls and ribbons
  • Remote printer management with ZebraLink™



Applications:

  •  🏥 Healthcare
  •  📦 Logistics
  •  ⚙️ Manufacturing
  • 🛢️Chemical
  • 💊Pharmaceutical



Specifications:

Printing Technology Thermal Transfer or Direct Thermal
Resolution 203 dpi / 300dpi
Print Speed (Maximum) 10"/254 mm per second (203 dpi)
6"/152.4 mm per second (300 dpi)
Print Width (Maximum) 4.25" (108 mm) to 8.8" (224 mm)
Minimum Non-Continuous Label Length
0.25"/6 mm (Rewind mode)
0.5"/13 mm (Peel mode)
0.7"/18 mm (Tear-off mode)
1.5"/38 mm (Cutter mode)
Media type: Continuous, die-cut gap, black mark, notch or hole
Media Width (min to max): 4.25" (108 mm) to 8.8" (224 mm)
Media Thickness (min to max): 0.003"/0.076 mm to 0.012"/0.305 mm
Media Roll Size (max), Core Size: 8.0" (203 mm) outside diameter on a 3" (76 mm) inside diameter core
Ribbon Outside Diameter 3.2"/81.3 mm
Maximum Ribbon Length 1476'/450 M
984'/300 M
Ribbon Width 4.25" (108 mm) to 8.6" (220 mm)
Ribbon Core I.D. 1.0"/25.4 mm
Media Sensor: Transmissive and reflective
Main Interface: USB 2.0, RS-232 Serial, and bi-directional Parallel port with auto detect, Internal ZebraNet® 10/100 Print Server (Ethernet)
Options & Accessories

Clear media side bi-fold door–allows shorter media door opening radius Full-width rotary knife cutter and catch tray–operates under software control cutting labels individually or in strips
Media rewind spindle–rewinds finished roll internally onto 3" (76 mm) core or enables label peel and liner rewind
Applicator interface – provides status and control signals for applicators and remote control devices
Media supply spindle for 3" (76mm) core or 40mm core
Additional fonts

Case: Zebra's OpenACCESS Clamshell Design
Control panel: Full-function front panel and large, multilingual, back-lit LCD display with user-programmable password protection
RAM (standard Memory): 64 MB on-board linear Flash memory; 16 MB SDRAM Flash memory
Drivers and software: Free-of-charge ZebraDesigner software, including set-up using Zebra Setup Utilities
Barcode Symbologies

Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case C Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, GS1 DataBar (RSS), Aztec

Fonts and Graphics

Unicode™-compliant Global Printing
Bitmap fonts A through H and GS symbols are expandable up to 10 times, height and width independent
Smooth scalable font Ø (CG Triumvirate™ Bold Condensed*) is expandable dot-by-dot, height and width independent
IBM® Code Page 850 International Characters
Supports user-defined fonts and graphics — including custom logos
61 MB user-available non-volatile memory storage for downloadable objects 12 MB user-available SDRAM
Bitmap fonts A through H and GS symbols are
*Contains UFST® from Agfa Monotype Corporation

Size (W x D x H) and Weight:

H: 15.5" / 393.7 mm

W: 15.81" / 401.6 mm

D: 20.38" / 517.5 mm

Weight: 72 lbs. / 32.7 kg



Additional Information
dpi

203, 300
