Zebra ZD421T

Sale price SGD 1,088.00
view

2 People are viewing this right now

Direct Thermal or Thermal Transfer: Thermal Transfer
dpi: 203
Connectivity: USB
Add to Wishlist Add to Compare
Discover our machines

Elevate your expectations with advanced, compact printers, built for enduring performance

Simple to Setup, Use and Manage Today

You need a reliable printer that delivers quality performance, now and for years to come. It needs to offer key features, and be easy to set up, operate, manage and maintain–onsite or remotely. It needs to be secure, whether it is integrated onto your network or not, to prevent downtime and costly cyberattacks. You need it. Zebra delivers it, for more than 50 years. We design our printers to match your workflows, ensuring they are hassle-free and ready to work. Day in and day out. We’re always innovating to deliver the best to help you advance your business and be ready for what’s next.



Features:

  • Choice of Direct Thermal (ZD421) or Thermal Transfer (ZD421t) models
  • Print resolution: 203 dpi standard, 300 dpi optional
  • Print width up to 4.09 in / 104 mm
  • Print speed up to 6 ips (203 dpi) / 4 ips (300 dpi)
  • New 5-button user interface with intuitive status icons
  • Field-upgradable media handling (peeler, cutter) and communications options
  • Connectivity: USB, USB Host, Ethernet, Serial, Bluetooth, Wi-Fi (optional)
  • Compatible with Zebra’s Print DNA software suite for setup, security, and management
  • Easy-to-use clamshell design for quick media and ribbon changes
  • Compact footprint, ideal for healthcare, retail, logistics, and light manufacturing



Applications:

  •  🏥 Healthcare
  •  🚚Transportation
  •  ⚙️Manufacturing
  • 📦🏬Warehouse & Logistics
  • 🛒Retail



Specifications:

Printing Technology Thermal Transfer and Direct Thermal

Resolution

  • 203 dpi/8 dots per mm
  • 300 dpi/12 dots per mm (optional)
Print Speed (Maximum) 6 in./152 mm per second (203 dpi)
4 in./102 mm per second (300 dpi)
Print Width (Maximum) ZD411: 2.2 in./56 mm for 203 dpi
2.13 in./54 mm for 300 dpi
ZD421: 4.09 in./104 mm for 203 dpi
4.16 in./106 mm for 300 dpi
ZD421 Thermal Transfer Cartridge: 4.09 in./104 mm for 203 and 300 dpi
Print Length



6 in./152 mm per second (203 dpi)
4 in./102 mm per second (300 dpi)



Media type:

Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands

Media Width (min to max):

ZD411:
0.585 in./15 mm to 2.36 in./60 mm
ZD421 Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm
ZD421 Thermal Transfer Roll: 0.585 in./15 mm to 4.41 in./112 mm
ZD421 Thermal Transfer Cartridge: 0.585 in./15 mm to 4.65 in./118 mm

Media Thickness (min to max): ZD411: 0.0024 in./0.06 mm min;
0.0075 in./0.1905 mm max. (tear-off mode only)
ZD421: 0.003 in. (0.08 mm) min.;
0.0075 in. (0.19 mm) max.
Media Roll Size (max), Core Size: Maximum outer diameter: 5.00 in./127 mm
Core inner diameter: 0.5 in./12.7 mm and
1.0 in./25.4 mm standard, 1.5 in./38.1, 2.0 in./50.8 mm and 3.0 in./76.2 mm using optional adapters
Maximum Ribbon Length ZD411: 243 ft./74 m
ZD421 Roll: 984 ft. /300 m; 243 ft. /74 m
ZD421 Cartridge: 243 ft. /74 m
Ribbon Width ZD411: 1.3 in./33 mm–2.24 in./58 mm
ZD421 Roll: 1.33 in./33.8 mm–4.3 in./109.2 mm
ZD421 Cartridge: 4.3 in./109.2 mm
Ribbon Core I.D. 300 m ribbon 1 in./25.4 mm
74 m ribbon 0.5 in./12.7 mm
Media Sensor: Full width, moveable reflective/black mark sensor; multi-position transmissive/gap sensor
Main Interface:
  • USB 2.0, USB Host
  • Printer setup mobile app for Android and iOS via BLE (Bluetooth Low Energy 5) connection*
    * BLE is provided for use with Zebra printer setup mobile app only
Options & Accessories
  • Healthcare Model – White color scheme, disinfectant-ready plastics, UV-resistant housing, sealed button interface, and healthcare-compliant power supply.

  • Media Handling – Optional field-installable dispenser/peeler with sensor, or cutter for easy media management.

  • Communications – Multiple connectivity choices: Ethernet, Serial, Wi-Fi (5/6), and Bluetooth (4.1/5.3), available as factory or field installable.

  • Battery – Optional battery powers the printer for a full shift at maximum speed, compatible with all media handling options.

  • Carrying Case – Portable case with handles and strap to transport the printer and battery easily to point of use.

  • Enclosed Power Supply – Attached power supply accessory for a cleaner, cord-free installation.

  • Keyboard Display Unit – ZKDU unit for stand-alone, PC-free printing applications.

  • Mounting Adapter Bracket – Allows installation in the same footprint as legacy Zebra models (GK420, LP/TLP2824).

Case:

Dual-wall frame construction

Control panel:

5 status icon, 3 button user interface

RAM (standard Memory): 512 MB Flash; 256 MB SDRAM
Drivers and software: Free-of-charge ZebraDesigner software, including set-up using Zebra Setup Utilities
Barcode Symbologies

Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard
2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code, Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec

Fonts and Graphics

16 resident expandable ZPL II bitmap fonts, two resident scalable ZPL fonts, five resident expandable EPL2 fonts, native open-type font support, Unicode compliant. China units include SimSun simplified Chinese font
64 MB user available non-volatile memory,
8 MB user available SDRAM

Size (W x D x H):

ZD411 Direct Thermal:
8.6 in. L x 4.5 in. W x 6.0 in. H
220 mm L x 115 mm W x 151 mm H
ZD411 Thermal Transfer:
9.56 in. L x 5.46 in. W x 6.66 in. H
242.9 mm L x 138.7 mm W x 169.2 mm H
ZD421 Direct Thermal:
8.69 in. L x 6.98 in. W x 5.93 in. H
220.8 mm L x 177.5 mm W x 150.7 mm H
ZD421 Thermal Transfer Roll:
10.5 in. L x 8.0 in. W x 7.44 in. H
267 mm L x 202 mm W x 189 mm H
ZD421 Thermal Transfer Cartridge:
10.0 in. L x 8.0 in. W x 7.0 in. H
254 mm L x 202 mm W x 177 mm H

Weight:

ZD411 Direct Thermal:
2.2 lb./1.0 kg
ZD411 Thermal Transfer:
3.59 lb./1.629 kg
ZD421 Direct Thermal:
2.98 lbs./1.35 kg
ZD421 Thermal Transfer Roll:
4.52 lbs./2.05 kg
ZD421 Thermal Transfer Cartridge:
5.0 lbs./2.3 kg



Additional Information
Direct Thermal or Thermal Transfer

Direct Thermal, Thermal Transfer

dpi

203, 300

Connectivity

USB, USB & Ethernet
