Home Zebra ZQ511

Zebra ZQ511

view

16 People are viewing this right now

Click To Enquire Add to Wishlist Add to Compare
Description

Exceptional durability and reliability for the toughest environments

Get More: Extra Features, Quality Construction, Exceptional Value

The Zebra ZQ500 Series, including the ZQ511 and ZQ521, delivers rugged, best-in-class mobile printing designed for the harshest environments. Built to military-grade standards, these printers withstand extreme drops, shocks, and environmental challenges while offering IP54 protection (upgradable to IP65). With support for receipts, labels, linerless media, and optional RFID, they provide versatile, on-demand printing for industries that demand durability and reliability.



Features:

  • Ultra-rugged design, built to military standard MIL-STD 810G for drop and shock resistance
  • Withstands 1300 tumbles from 1 m / 3.3 ft
  • IP54-rated protection against dust and liquid (upgradable to IP65 with optional case)
  • Drop-tested up to 6.6 ft / 2 m (standard), 10 ft / 3 m with exoskeleton case
  • Optimized for mobile printing: receipts, labels, linerless media, RFID tags (optional models)
  • Print widths: 72 mm (3 in., ZQ511) and 104 mm (4 in., ZQ521)
  • Multiple connectivity options: Bluetooth, Wi-Fi, USB
  • Enhanced durability with over-molding for long life in tough environments
  • High-performance processor for fast printing and smooth operation



Applications:

  •  🏥 Healthcare
  •  📦🚚 Transportation & Logistics
  •  ⚙️ Manufacturing
  •  🏷️ Retail



Specifications:

Printing Technology Direct Thermal
Resolution 203 dpi
Print Speed (Maximum) Up to 5 in./127 mm per second (with Draft Mode enabled)
Print Width (Maximum) ZQ511: 2.83 in./72mm
ZQ521: 4.09 in./104mm
Maximum Label Length Maximum: 39 in.
Media type: Receipt, Gap/Black-mark Label, Tag, Linerless, RFID (Note: ZQ511R/ZQ521R require black mark RFID media and do not support gap sensing)
Note: ZQ511R/ZQ521R require black mark RFID media and do not support gap sensing
Media Width (min to max): ZQ511: 1.38 in./35 mm to 3.15 in./80 mm+1 mm
ZQ521: 2.0 in./50.8 mm to 4.45 in./113 mm+1 mm
Media Thickness (min to max): 0.0063 in./0.1600 mm for labels and
0.0055 in./0.1397 mm for tag/receipt
Media Roll Size (max): ZQ511: 2.0 in./51 mm
ZQ521: 2.24 in./57 mm
CPCL Barcode Symbologies • Barcode Ratios: 1.5:1, 2:1, 2.5:1, 3:1, 3.5:1
• Linear Barcodes: Code 39, Code 93, UCC/EAN128, Code 128, Codabar (NW-7), Interleaved 2-of-5, UPC-A, UPC-E, 2 and 5 digit add-on, EAN-8, EAN-13, 2 and 5 digit add-on
• 2D Barcodes: PDF417, MicroPDF417, MaxiCode, QR Code, GS1/DataBar™ (RSS) family, Aztec, MSI/Plessey, FIM Postnet, Data Matrix, TLC39
ZPL Barcode Symbologies • Barcode Ratios: 2:1, 3:1, 5:2, 7:3
• Linear Barcodes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC-A and UPC-E with EAN 2 or 5 digit extensions, Planet Code, Plessey, POSTNET, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Codabar, and GS1 DataBar (RSS)
• 2D Barcodes: PDF417, MicroPDF-417, Code 49, TLC39, Maxicode, Codablock, Data Matrix, QR code, Aztec
Standard Fonts 25 bitmapped, 1 smooth, scalable (CG Triumvirate Bold Condensed, contains UFST™ from Agfa Monotype Corporation)
Included in All Models and Part Numbers Scalable Fonts: Swiss721 (supporting Latin, Cyrillic, Hebrew and Arabic characters)
Additional Asian Fonts Supported

Group A: Part Numbers supporting Indonesia, Taiwan, Korea, Malaysia, Australia, New Zealand, Sri Lanka, India include: Scalable Traditional Chinese Characters: NotoMono, Bitmap: 24x24 MKai, 16x16 New Sans MT, Scalable Korean Characters: NotoMono

Group B: Part Numbers supporting, Singapore, Thailand, Philippines, HongKong and Vietnam include: Scalable Traditional Chinese characters: NotoMono and Bitmap 16x16 NewSans MT. Scalable Thai Characters: Angsana, Scalable Vietnamese Characters: SourceCodePro and Bitmap 16x16 Utah

Group C: Part Numbers supporting China include: Scalable Simplified Chinese Characters: Hans and Bitmap 24x24 Msung, 16x16 SimSun

Group J: Part Numbers supporting Japan include: Scalable NotoMono and Square Gothic J MT, Bitmap 16x16, 24X24 Square Gothic J MT

Media Sensor: Black mark and gap media sensing using fixed center position sensors (Note: RFID models do not support gap sensing)
Main Interface:
  • Android, Apple iOS, Windows™ Mobile connectivity
  • Bluetooth specification 4.1 EDR + LE
  • Fast roaming 802.11r supported
  • USB On-The-Go port
Options & Accessories
  • RFID encoding
  • 6500 mAh PowerPrecision+
  • Extended Battery (retrievable, rechargeable Li-Ion)
  • Linerless printing (with silicone platen roller only)
  • AC Adaptor / Dual Charing Vehicle Adaptor
  • Vehicle Cradle
  • 4-Slot Power Station
  • 12-24V DC Power Supply
  • Extended Spare Smart Battery 6500mAh
  • Battery Chargers (1-slot or 3-slot)
  • Exoskeleton
Case: Zebra's Clamshell Design
Operating System Link-OS™ printer operating system
RAM (standard Memory): 256MB RAM, 512MB Flash (standard)
8MB RAM, 64MB Flash (user available)
Drivers and software: Free-of-charge ZebraDesigner Essentials, including set-up using Zebra Setup Utilities
Emulations (Languages):

Zebra DNA For Printers

Size (W x D x H):

ZQ511: 5.9 in. L x 4.7 in. W x 2.4 in. H
150 mm L x 120 mm W x 62 mm H

ZQ521: 6.2 in. L x 6.1 in. W x 2.6 in. H
158 mm L x 155 mm W x 67 mm H

Weight with Standard Battery

ZQ511: 1.39lbs/0.63 kgs
ZQ521:
1.73lbs/0.79 kgs

Weight with Extended Battery

ZQ511: 1.62lbs/0.72 kgs
ZQ521:
1.96lbs/0.89 kgs
